MSI A75A-G55
Compare This
Add to Wishlist

MSI A75A-G55

Building on the strengths of the A75MA-G55, MSI has released the A75A-G55, a full-size ATX motherboard featuring Military Class II components, OC Genie II, ClickBIOS, i-Charger, and support for USB 3.0 and SATA 6Gbps.

Product Specification

Processor Support and Chipset Type
  • AMD Liano APU in FM1 package
  • AMD Hudson D3 Chipset
  • 4 x 1.5V DDR3 DIMM sockets, supports dual channel mode
  • Supports DDR3 1066/1333/1600 DRAM
  • Max. capacity of system memory: 32GB
  • 6 x SATA 6Gb/s connectors by AMD A75
  • Support for RAID 0, RAID 1, and RAID 10
  • Chip integrated by Realtek ALC887 (A75A-G45)
  • Chip integrated by Realtek ALC892 (A75A-G55)
  • Flexible 8-channels audio-out
  • Compliant with Azalia 1.0 Spec
  • Supports AMD Dual Graphics Technology with "Lynx" platform
  • Supports AMD CrossFireXTM Technology
Networking 1 x Realtek RTL8111E chip (10/100/1000 Mbit)
FireWire (IEEE 1394) N.A.
Rear I/O
  • 4 x USB 2.0/1.1 ports
  • 1 x PS/2 keyboard/mouse port
  • 1 x VGA Port
  • 1 x DVI-D port
  • 1 x HDMI port
  • 2 x USB 3.0/2.0 ports
  • 1 x RJ-45 port
  • 6 x flexible audio ports
Internal Connectors
  • 1 x ATX 24-pin power connector
  • 1 x ATX 4-pin 12V CPU power connector
  • CPU x 1 / System x 2 FAN connectors
  • 1 x Front panel audio connector
  • 1 x Front panel connector
  • 2 x USB 2.0 connectors
  • 1 x USB 3.0 connector
  • 6 x Serial ATA 6Gb/s connectors
  • 1 x Serial port connector
  • 1 x DLED3 connector
  • 1 x Clear CMOS jumper
  • 1 x Chassis Intrusion connector
Expansion Slots
  • 1 x PCI Express x16 slot, running at x16 (PCIEX16)
  • 1 x PCI Express x16 slot, running at x4 (PCIEX4)
  • 3 x PCI Express x1 slots
  • 2 x PCI slots
Other Features
  • Second-generation military class standard materials and parts with Hi-c CAP, SFC and Solid CAP which demonstrate extreme quality and stability
  • Supports the newest OC Genie II overclocking technology
  • Supports Winki 3
  • Supports the UEFI architecture Click BIOS Concept
  • Supports the i-Charger charging function, allowing your iPad to be fully charged at any time
Form Factor ATX Form Factor; 26.4cm x 30.5cm
